Socket (12pt Flank) Finish: Mat Finish
6.35 mm (1/4")
SIZE D1(mm) Max D2(mm) L(mm) W.(g)
3.2 5.9 12 25 10
4 6.9 12 25 10
4.5 7.5 12 25 10
5 8.2 12 25 10
5.5 8.8 12 25 10
6 9.6 12 25 11
7 10.9 12 25 11
8 12 12 25 12
9 13 12 25 15
10 14 12.3 25 116
11 16 14 25 23
12 17 15 25 25
13 18 16 25 29
14 19.7 17 25 36

9.5 mm (3/8")
SIZE D1(mm) Max D2(mm) L(mm) W.(g)
6 10 17 28 25
7 11 17 28 25
8 12.2 17 28 25
9 13.5 17 28 25
10 14.7 17 28 25
11 16 17 28 25
12 17 16.5 28 25
13 18 17 28 28
14 19.7 18 28 38
15 21 19 28 40
16 22 19 28 41
17 23.5 21 28 59
18 24.7 22 30 68
19 26 22 30 68
20 27.2 24 30 65
21 28 24 30 65
22 29.7 26 30 83
23 31.8 27 30 87
24 32 27 30 87

12.7 mm (1/2")
SIZE D1(mm) Max D2(mm) L(mm) W.(g)
8 14 22 38 47
9 14.3 22 38 48
10 15.5 22 38 48
11 16.7 22 38 50
12 18 22 38 50
13 19.2 22 38 53
14 20.5 22 38 54
15 21.7 21.3 38 56
16 22 21.3 38 53
17 24 22 38 61
18 25.5 23 38 79
19 26 23 38 65
20 28 24 38 79
21 28 24 38 77
22 30 26 38 94
23 31.7 27 38 104
24 32 27 40 107
25 34 29 42 140
26 35.5 29.5 42 131
27 36 30 42 145
28 38 32 42 177
29 38 32 42 164
30 40 34 45 193
32 42 36 45 212
36 48 40 60 310
